360 degree to spurt the code, regardless of previous dynasties down towards the arbitrary to spurt the code, full range, the angle coding meet production.
The machine operation or PC editor optional; color touch screen, WYSIWYG, simple operation; massive internal Chinese font; bitmap fonts, print and character height, arbitrarily set.
High level of industrial protection, to adapt to a variety of dust, humidity and other harsh industrial environment, strong and durable.
Complete ink. A variety of formulations of ink to meet different customer needs. This product is currently in the building materials including (wood board, carton, stone, building on the membrane, plate plywood, fiber board, light steel keel, etc.), wine, beverage, electronics, auto parts, food, cosmetic, pharmaceutical, rubber pipe and industry are widely used.
Standard function:
USB interface
The GB built-in fonts, bitmap fonts.
Automatic power saving function: standby condition, the display screen 10 seconds automatic dark, 5 minutes automatic shutdown.
Screen color touch online editing can be printed, what you see, the operation is simple.
Main features:
Stainless steel casing.
Screen color touch.
Host information storage 1000
Working temperature -40 C -20 C machine working as usual.
Relative humidity range: 10-90%[non condensing]
Spray printing function:
5 mm from the object of the best printing effect.
Speed 40 m / min.
Spray printing height: 1-18 mm.
Can spray a number of 8 lines.
Time, date, number and serial number.
Type of ink:
Oily ink color: black, red, green, blue, yellow, purple.
Fast drying ink color: black, red, purple, green, blue, yellow, white.
Technical parameter:
Input voltage: 8.4V.
Working current: 8.4V.
Battery voltage: 8.4V
Battery capacity: 2500mAh.
Machine size: 160X100X100mm
Continuous printing use time: more than 10 hours.
Standby time: more than 12 months.
