Structural material
High quality aluminum alloy, stainless steel
Laser type
Sealed CO2 laser
Laser wavelength
10.6 um
output power
10W/30W optional
Print material
Non metallic materials
Laser deflection system
High speed scanning vibrating mirror
print mode
Static and dynamic
Print speed
1-60 M / min adjustable
print font
SHX, TTF, dot matrix font
Print range
110mm*110mm
Minimum line width
0.04mm
Minimum character
0.3mm
character height
There is no limit to the marking time
Photoelectric switch
PNP, NPN can be
Encoder interface
Differential signal 5V
Red light localization
Optional
Red light interface
3V
communication interface
USB interface; RS232 serial port; SD card interface
Emergency stop switch
Yes
External control interface
Multiple external trigger and control output interface
Display Size
10.4 inch
Control system size
262mm*214.5mm*49mm
Cooling mode
Air cooling
Use temperature
5-35 C
Operating humidity
The relative humidity is lower than 95%, no frost
Power supply
AC 50HZ, 220V
Power
200W
